We are NC Rear Cylinder Press Brake Machine Manufacturers, we provide high quality C Rear Cylinder Press Brake Machine in India by Hi-Tech Machines India.
Hi-Tech Machines top-notch NC Rear Cylinder Press Brake Machine Manufacturers, Dealers, Suppliers, Exporters in India, offering the full collection of NC Rear Cylinder Press Brake Machines in India designed and engineered to meet standards demanded by modern manufacturing practices. Our aim for precision, reliability, and performance in bending and forming of sheet metals. Ideal with advanced features and a robust design, these NC RearCylinder Press Brake Machines are used in enterprises demanding accuracy and efficiency in bending solutions, covering industries from automotive and aerospace to metal fabrication.
We have designed our NC Rear Cylinder Press Brake Machines so that it give good performance even under heavy-duty as well as precision applications. All bending angles can be controlled and programmed very precisely by the operators of the machines. The results are extremely consistent every time. The machine is very capable of bending hordes of metals: mild steel, stainless steel, and many others. The in-built control system takes utmost care of material minimizing and ensuring a perfect bend.
With an immovable shell, our NC rear cylinder press brake machines can stand for the grades of heavyweight production lines. The robustness of the machine alludes to its durability toward wear and tear over the years so it can be looked upon as a worthy investment for companies interested in increasing productivity and quality. Moreover, we offer different kinds of customizing options to make a machine fit for the specific production needs of a customer.
Being the most trusted NC Rear Cylinder Press Brake Machine in India, we not only offer all types of machines from elite to just affordable, but also completely cater to after-sales support like installation, training, and maintenance services. Our customer-centric approach caters to getting the maximum return on the investment against purchasing a machine that delivers results and longevity.
Some of the top NC Rear Cylinder Press Brake Machine Dealers in India present an extensive range of high-grade Machines that are flexible enough to be applied in all types of Machines as follows:
We have added below a technical sheet of our NC Rear Cylinder Press Brake Machine that provides more technical information such as:
| Parameter | Specification |
|---|---|
| Machine Type | NC Rear Cylinder Press Brake |
| Bending Capacity | 20 to 1200 tons |
| Bending Length | 1000 mm to 6000 mm |
| Bending Accuracy | ± 0.1 mm to ± 0.5 mm |
| Max Bending Angle | 0° - 180° |
| Cylinders | Single or Double Rear Cylinders |
| Rear Cylinder Stroke | 100 mm to 1000 mm |
| Control System | NC |
| Axis Control | 2 to 4 Axis Control |
| Back Gauge Type | Motorized, Ball Screw, or Linear Guide |
| Back Gauge Stroke | 100 mm to 1000 mm (depending on machine size) |
| Ram Stroke Length | 100 mm to 300 mm |
| Main Motor Power | 7.5 kW to 75 kW |
| Hydraulic System | Proportional Valve or Servo-Hydraulic |
| Oil Tank Capacity | 150 to 800 liters |
| Max Pressure | 2000 to 3200 psi |
| Hydraulic Drive Type | Rear Cylinder Hydraulic Drive |
| Stroke Speed | 5 to 20 mm/sec |
| Working Speed | 5 to 15 mm/sec |
Being one of the most promising NC Rear Cylinder Press Brake Machine Manufacturers from India, every single type of NC Rear Cylinder Press Brake Machine has been designed with highly advanced features and allows all benefits such as-:
As NC Rear Cylinder Press Brake Machine Dealers , Suppliers in India, our Machines are highly demanded for multiple types of applications and used for improving performance, such as:
Hi-Tech Machines is a High-end NC Rear Cylinder Press Brake Machine Manufacturers, Dealers, Suppliers, Exporters in India. We also provide high-quality press brake machines as accuracy-based engineering products delivering faultless working performance and reliability. Besides offering products to focus on customer satisfaction and after-sale service we foresee that all your bending operations are properly warranted. Trust us to offer sophisticated solutions engineered by demand for your specific industrial needs thus ensuring optimum productivity
The frame provides the structural support and rigidity to the press brake. It ensures stability during the bending operation and supports the other components such as the hydraulic system, ram, and bed.
The bed, also called the lower beam or bedplate, provides support for the bottom of the workpiece during bending. It is usually equipped with a die set that helps shape the metal into the desired form. The bed may also have adjustable features to accommodate different die sets and workpiece sizes.
The hydraulic system is responsible for generating the force required to bend the metal. It typically consists of hydraulic cylinders, hydraulic pumps, valves, hoses, and a reservoir. The hydraulic pump pressurizes hydraulic fluid, which is then transferred to the hydraulic cylinders to actuate the bending process.
The ram, also known as the upper beam or slide, is the moving part of the press brake that applies force to the workpiece. It is controlled by the hydraulic system and moves vertically to perform the bending operation.
The die set consists of an upper and lower die that shapes the metal during bending. The upper die is mounted on the ram, while the lower die is fixed to the bed. Die sets come in various shapes and sizes to accommodate different bending requirements, such as V-dies, U-dies, and acute angle dies.
The back gauge is a positioning device located behind the bed that helps accurately position the workpiece for bending. It can be manually adjusted or controlled electronically, depending on the machine's capabilities. The back gauge ensures consistent bending accuracy and repeatability.
Modern hydraulic press brake machines are often equipped with a control system, which may include a CNC (Computer Numerical Control) interface. The control system allows operators to input bending parameters such as bend angle, bend length, and material thickness. CNC controlled press brakes offer precise control over the bending process and can automate repetitive tasks.
